Pumped-storage hydropower plants with underground reservoir: Influence of air pressure on the efficiency of the Francis turbine and energy production

Background on Pumped-Storage Hydropower

Pumped-storage hydropower (PSH) represents the most mature and widely deployed form of large-scale energy storage, functioning essentially as a giant rechargeable battery for the electrical grid. The technology relies on the potential energy of water, utilizing two reservoirs at different elevations. During periods of low electricity demand or high renewable generation, excess power drives pumps to move water from the lower reservoir to the upper one. When demand peaks, water is released back through turbines to generate electricity, providing critical flexibility, frequency regulation, and inertia to the power system.

Underground Reservoirs

A significant subset of PSH facilities utilizes underground reservoirs, particularly for the upper storage basin. This configuration is often employed in mountainous terrain or where surface land use is at a premium. The upper reservoir is typically created by excavating a cavern within a mountain or rock formation, or by utilizing natural lakes fed by underground aquifers. The lower reservoir may also be partially or fully subterranean, depending on the geological profile.

The primary advantage of underground reservoirs is the reduction of surface footprint, minimizing environmental impact on forests, agricultural land, and local communities. Additionally, underground structures can offer thermal stability, reducing evaporation losses compared to open-air surface reservoirs. However, the construction of underground reservoirs involves complex geotechnical engineering. The rock mass must possess sufficient strength and permeability characteristics to contain the water head without excessive seepage. Grouting and lining are often required to ensure structural integrity and minimize water loss.

The energy storage capacity of a PSH plant is fundamentally determined by the volume of water stored and the effective head (the vertical distance between the two reservoirs). The potential energy E can be approximated by the formula E=ρ⋅g⋅V⋅H, where ρ is the density of water, g is the acceleration due to gravity, V is the volume of water, and H is the net head. Underground reservoirs allow for significant head heights, especially when carved into steep mountain slopes, thereby increasing the energy density of the storage system. The specific characteristics of the rock formation, including its porosity and fracture patterns, directly influence the design and efficiency of these underground storage solutions.

Impact on Energy Production

The operational efficiency of pumped storage hydropower plants is fundamentally linked to the thermodynamic properties of the working fluid and the surrounding atmospheric conditions. In these systems, water serves as the primary energy storage medium, circulating between upper and lower reservoirs to convert potential energy into electrical energy and vice versa. While water is often treated as incompressible, the presence of dissolved and entrained air within the turbine runner significantly influences hydraulic performance. Variations in ambient air pressure directly affect the saturation pressure of water, which in turn dictates the volume of air released from the water column as it passes through the turbine stages.

When ambient air pressure decreases, typically at higher altitudes or during specific meteorological events, the saturation pressure of water drops. This reduction causes more air to come out of solution within the turbine runner. The resulting air-water mixture alters the effective density and viscosity of the fluid passing through the blades. The overall efficiency of the turbine, denoted as η, can be expressed as the ratio of output power Pout to input hydraulic power Pin:

η=PinPout=ρgQHρgQHηmechηvol

Where ρ represents the density of the fluid, g is the acceleration due to gravity, Q is the volumetric flow rate, and H is the net head. The term ηvol, or volumetric efficiency, is particularly sensitive to air content. As air pressure drops, the increased air volume fraction reduces the effective density ρ of the mixture. This reduction leads to a decrease in the torque generated by the runner for a given flow rate, thereby lowering the mechanical efficiency ηmech.

Impact on Net Energy Yield

The cumulative effect of these efficiency losses translates directly to the overall energy production of the plant. During peak discharge periods, a lower turbine efficiency means that a greater volume of water must be released from the upper reservoir to generate the same amount of electrical energy. This reduces the effective capacity factor of the plant. Conversely, during the pumping phase, the efficiency of the pump-turbine units is also influenced by air content, though the impact is generally less pronounced than during generation. The net energy yield Enet over a given period T is calculated as:

Enet=∫0T(Pgen(t)−Ppump(t))dt

Where Pgen and Ppump are the instantaneous generation and pumping powers, respectively. Variations in air pressure can cause Pgen to fluctuate independently of the head and flow rate, introducing variability into the energy yield. Plant operators must account for these atmospheric effects in their dispatch strategies to optimize the overall round-trip efficiency of the pumped storage system.
