Overview

The Longtan Dam is a major hydroelectric infrastructure project located on the Hongshui River in Tian'e County, within the Guangxi Zhuang Autonomous Region of China. The Hongshui River serves as a significant tributary to the Xi River, which ultimately feeds into the Pearl River system. This facility is constructed using roller-compacted concrete (RCC) technology and is designed as a gravity dam. It holds the distinction of being the tallest dam of its specific structural type in the world. The structure stands at a height of 216.2 metres and spans a length of 849 metres. These dimensions contribute to its status as a prominent engineering achievement in global hydropower development.

The primary function of the Longtan Dam is hydroelectric power production. The complex includes an underground power station that harnesses the water flow from the Hongshui River to generate electricity. In addition to energy generation, the dam plays a critical role in regional flood control. By regulating the water levels of the Hongshui River, it helps mitigate flooding impacts on downstream communities and agricultural lands in the Guangxi region. The facility also enhances navigation capabilities along the river, facilitating transport and trade through the Pearl River basin.

The dam's infrastructure is designed to handle substantial water volumes and operational demands. It features seven surface spillways and two bottom outlets, which allow for efficient water management and flow regulation. The project also includes the Longtan ship lift, which is part of the broader dam complex. This ship lift is designed to be the tallest ship lift system in the world, further improving navigational efficiency for vessels traversing the river. The operational status of the Longtan Dam is currently active, having been commissioned in 2009. Its installed capacity is 6426 MW, making it a significant contributor to the regional energy mix.

Why it matters

The Longtan Dam holds a distinct position in global civil engineering as the tallest roller-compacted concrete (RCC) gravity dam in the world, standing at 216.2 metres (709.3 ft) in height. This structural achievement is not merely a record of vertical scale; it represents a significant technological application of RCC technology on a massive river system. The dam spans 849 m (2,785 ft) across the Hongshui River in Tian'e County, Guangxi Zhuang Autonomous Region, China. Its construction utilized an underground power station and a complex hydraulic layout including seven surface spillways and two bottom outlets, designed to manage the substantial flow of the Hongshui, a key tributary of the Xi River and the broader Pearl River basin. The operational status of the facility, commissioned in 2009, confirms its role as a mature infrastructure asset with a total installed capacity of 6426 MW.

Transforming the Upper Hongshui River

Beyond its structural metrics, the Longtan Dam plays a critical strategic role in regional hydrology and logistics. It is a central component in the effort to transform the upper Hongshui River into a 'golden waterway' for the landlocked provinces of Guizhou and Guangxi. Prior to the dam's construction, the river's navigability was significantly hindered by natural topographical features. The project specifically targeted the submergence of over 300 shoals that previously fragmented the river's flow and restricted vessel size and frequency. By smoothing these obstacles, the dam facilitates a more continuous and efficient transport corridor, linking inland production centers in Guizhou to the coastal trade routes accessible via the Pearl River Delta.

The integration of the Longtan ship lift, which is part of the dam complex, further enhances this navigational capability. This lift system is designed to be the tallest ship lift system in the world, addressing the significant elevation changes created by the 216.2-metre height of the dam structure itself. This infrastructure allows for the movement of cargo vessels that might otherwise struggle with traditional lock systems or the river's natural gradient. The combination of flood control, hydroelectric power generation, and enhanced navigation underscores the dam's multi-functional utility. It serves not just as an energy producer with a 6426 MW output, but as a linchpin in the economic integration of southwestern China's riverine networks, reducing transport costs and increasing the throughput capacity for regional trade.

Construction history and timeline

Planning for the Longtan Dam began in the 1950s, with preliminary construction efforts dating back to the 1940s. The formal start of construction occurred in 2001, marking the beginning of significant development for this large roller-compacted concrete (RCC) gravity dam on the Hongshui River. The project involved extensive excavation and the creation of tunnels, including an underground power station.

Construction Timeline

Year Event
1940s Preliminary construction efforts began.
1950s Planning for the dam commenced.
2001 Formal start of construction.
2003 River diversion took place.
2006 Impounding of the river began.
2009 Full operation commenced.

The construction of the Longtan Dam involved the creation of seven surface spillways, two bottom outlets, and an underground power station. The dam stands 216.2 metres high and is 849 metres long, making it the tallest of its type in the world. The Longtan ship lift, part of the dam complex, is noted as the tallest ship lift system in the world.

What are the technical specifications of Longtan Dam?

Longtan Dam is a large roller-compacted concrete (RCC) gravity dam situated on the Hongshui River in Tian'e County, Guangxi Zhuang Autonomous Region, China. The structure serves as a tributary to the Xi River and the Pearl River basin. The facility is designed for hydroelectric power production, flood control, and navigation.

Structural Components

The dam complex includes seven surface spillways and two bottom outlets to manage water flow and flood control. An underground power station houses the hydroelectric generation equipment. The Longtan ship lift, part of the dam complex, is designed to be the tallest ship lift system in the world, facilitating navigation along the river.

Technical Specifications

Parameter Value
Height 216.2 m
Length 849 m
Reservoir Volume 27,270,000,000 m3
Installed Capacity 6426 MW
Annual Generation 18.7 TWh
Spillways 7 surface
Bottom Outlets 2
Power Station Type Underground

How does the Longtan ship lift enhance navigation?

The Longtan Dam complex significantly enhances navigation on the Hongshui River through the integration of the Longtan ship lift, a critical component designed to overcome the substantial vertical elevation change created by the 216.2-metre-high structure. Without such a mechanism, the river's flow would be interrupted by the dam's height, forcing vessels to navigate through potentially turbulent surface spillways or wait for extended periods in a traditional lock system. The ship lift provides a more efficient and faster alternative for maritime traffic, directly addressing the navigability challenges posed by the dam's impressive scale and location in Tian'e County. The Longtan ship lift is distinguished as the tallest ship lift system in the world. This engineering achievement is essential for maintaining the continuity of the Hongshui River as a vital waterway, which serves as a tributary to the Xi River and ultimately the Pearl River basin. The lift is specifically engineered to handle vessels with a capacity of up to 500 tonnes. This tonnage allows for a diverse range of commercial and transport boats to traverse the dam, facilitating the movement of goods and passengers between the upper and lower sections of the river. By accommodating these 500-tonne vessels, the lift ensures that the hydroelectric development does not disproportionately hinder the regional logistics network. The operation of the ship lift complements the dam's other primary functions, including hydroelectric power production and flood control. While the underground power station and seven surface spillways manage water flow and energy generation, the navigation infrastructure ensures that the Hongshui River remains a functional corridor for transport. The lift's ability to raise and lower boats efficiently reduces transit times compared to traditional locking mechanisms, which can be time-consuming for smaller vessels. This improvement in navigability supports the broader economic activity in the Guangxi Zhuang Autonomous Region by keeping the river open for consistent maritime traffic. The design of the ship lift reflects the comprehensive planning involved in the Longtan Dam project, which utilized roller-compacted concrete (RCC) gravity dam technology. The integration of such a large-scale navigation aid within the dam complex highlights the multi-purpose nature of the infrastructure. It balances the need for significant hydroelectric output, with a capacity of 6426 MW, with the necessity of maintaining river connectivity. The presence of two bottom outlets further aids in water management, but the ship lift remains the primary solution for vertical navigation. This infrastructure ensures that the Hongshui River continues to serve as a key transport route, linking inland areas with the broader Pearl River delta.

Geographic and hydrological context

It is constructed across the Hongshui River, a significant waterway that serves as a major tributary to the Xi River, which in turn feeds into the Pearl River basin. This geographic positioning places the dam within a complex hydrological network critical to southern China's water management and energy production. The Hongshui River's flow characteristics are directly influenced by the dam's presence, altering local hydrology through the creation of a substantial reservoir and the regulation of downstream discharge.

Structural and Hydrological Integration

The dam's design as a large roller-compacted concrete (RCC) gravity structure is integral to its interaction with the river system. This immense scale allows for significant water retention, directly impacting flood control capabilities and ensuring a steady flow for hydroelectric power generation. The structure includes seven surface spillways and two bottom outlets, which are essential for managing water levels and sediment transport within the Hongshui River. These features help mitigate flooding risks for downstream communities and maintain ecological flow requirements, although the specific ecological impacts are not detailed in the primary sources.

Beyond power generation and flood control, the Longtan Dam complex plays a crucial role in regional navigation. The inclusion of the Longtan ship lift, described as the tallest ship lift system in the world, enhances connectivity along the Hongshui River and its tributaries. This infrastructure facilitates the movement of goods and people, integrating Tian'e County more closely with the broader Pearl River economic zone. The dam's operational status, commissioned in 2009, marks a key milestone in the hydrological management of the Guangxi region, providing a multifaceted solution to energy, water, and transport needs.

Frequently asked questions

When was Longtan Dam completed?

The Longtan Dam was commissioned in 2009, marking the beginning of its operational phase on the Hongshui River. This completion date is confirmed by structured data sources identifying the entity's inception year as 2009. It serves as a critical infrastructure component for hydroelectric power production, flood control, and navigation along this tributary of the Xi River and the Pearl River system. The project represents a significant engineering achievement in the region's energy infrastructure development.

What is the height of Longtan Dam?

The Longtan Dam stands at a height of 216.2 metres. This dimension makes it the tallest roller-compacted concrete (RCC) gravity dam in the world. The structure is also 849 metres long, forming a substantial barrier across the Hongshui River. Its design incorporates seven surface spillways, two bottom outlets, and an underground power station to manage water flow and generate electricity efficiently. The dam's considerable height is a key factor in its hydroelectric potential and flood control capabilities.

How much power does Longtan Dam generate?

The Longtan Dam has an installed capacity of 6426 MW. This significant power output contributes substantially to the regional energy grid in China. The hydroelectric power plant utilizes the water flow from the Hongshui River to drive turbines within the underground power station. The facility is currently operational, providing a consistent source of renewable energy. The dam's design optimizes water usage for both power generation and navigation, enhancing the overall utility of the water resource.

Is Longtan Dam the tallest dam in the world?

While there may be taller dams constructed using different materials or designs, Longtan holds the specific record for RCC gravity dams. Its height of 216.2 metres distinguishes it from other structures of its type globally. The dam complex also includes the Longtan ship lift, which is projected to be the tallest ship lift system in the world, further enhancing the navigational capabilities of the Hongshui River. This combination of height and specialized construction technique underscores the engineering significance of the project.

Summary

The Longtan Dam stands as a landmark achievement in global hydroelectric infrastructure, recognized as the world's tallest roller-compacted concrete (RCC) gravity dam. Located on the Hongshui River in Tian'e County, within China's Guangxi Zhuang Autonomous Region, this massive structure plays a critical role in the energy and water management systems of the Pearl River basin. With an installed capacity of 6426 MW, the facility represents a significant contribution to the regional power grid, leveraging the hydraulic potential of the Hongshui River, a key tributary of the Xi River. The dam was commissioned in 2009, marking the culmination of extensive engineering efforts to harness water resources for electricity generation, flood mitigation, and improved river navigation.

The engineering scale of the Longtan Dam is defined by its exceptional dimensions. Rising to a height of 216.2 metres and spanning a length of 849 metres, the structure exemplifies the capabilities of RCC technology in large-scale gravity dam construction. Its status as the tallest dam of its type globally underscores the technical advancements in concrete compaction and structural stability required to withstand the hydrostatic pressures of the reservoir. The dam's design integrates multiple functional components, including seven surface spillways and two bottom outlets, which work in concert to manage water flow and maintain structural integrity during varying hydrological conditions.

Beyond power generation, the Longtan Dam complex includes an underground power station and the Longtan ship lift, which is designed to be the tallest ship lift system in the world. This navigational enhancement significantly improves connectivity along the Hongshui River, facilitating more efficient transport of goods and resources within the Guangxi region. The integration of flood control mechanisms further highlights the dam's multifaceted utility, providing essential protection to downstream communities and agricultural lands. As an operational facility, the Longtan Dam continues to serve as a vital node in China's energy infrastructure, demonstrating the strategic importance of large-scale hydroelectric projects in balancing energy demand, water resource management, and regional economic development. The project remains a testament to the engineering precision required to manage complex river systems while delivering sustained energy output and navigational benefits.
