Overview
The Kimberlina Solar Thermal Energy Plant is a 5 MW solar thermal power facility located in Bakersfield, California, United States. It holds the distinction of being the first commercial solar thermal power plant constructed by Areva Solar, marking a significant milestone in the deployment of Compact Linear Fresnel Reflector (CLFR) technology for utility-scale energy generation. The plant is currently operational, having been completed and commissioned in 2008. As a pioneering project for Areva Solar, Kimberlina serves as a demonstration of how linear Fresnel systems can efficiently produce high-temperature steam for both electricity generation and industrial process heat applications.
Technology and Operation
The plant utilizes Compact Linear Fresnel Reflector (CLFR) technology, which distinguishes it from other concentrated solar power (CSP) systems such as parabolic troughs or solar towers. The core of the system consists of solar boilers equipped with groups of 13 narrow, flat mirrors. These mirrors individually track the sun’s movement across the sky, focusing solar radiation onto overhead pipes that carry water. This direct heating mechanism causes the water to boil directly into superheated steam, eliminating the need for secondary heat transfer fluids used in some other CSP designs.
The Kimberlina solar boiler is capable of achieving 750-degree F superheated steam, a temperature sufficient to drive turbines for electricity generation or to provide industrial steam for various processes including food production, oil extraction, and desalination. At the time of its completion, the plant represented the next generation of solar thermal technology, with subsequent designs aiming for 900-degree F superheated steam to further enhance thermal efficiency and expand the range of viable industrial applications. The 5 MW capacity makes it a notable entry in the portfolio of solar farms in California, contributing to the state’s diverse mix of renewable energy sources.
How does Compact Linear Fresnel Reflector technology work?
The Kimberlina Solar Thermal Energy Plant utilizes Compact Linear Fresnel Reflector (CLFR) technology to convert solar radiation into thermal energy. This system functions as a renewable energy solar boiler, designed to generate superheated steam for electricity generation or industrial processes. The core mechanism involves focusing sunlight onto fixed overhead pipes using an array of narrow, flat mirrors.
System Components and Operation
Each solar boiler unit at Kimberlina consists of a specific configuration of optical and thermal components. The system relies on individual tracking of mirrors to maintain optimal focus on the receiver pipes. The following table outlines the key components of the CLFR system as described in the source material.
| Component | Description |
|---|---|
| Mirrors | Groups of 13 narrow, flat mirrors per solar boiler |
| Tracking Mechanism | Individual tracking for each mirror to focus sun's heat |
| Receiver Pipes | Overhead pipes carrying water that boil directly into steam |
| Output | Superheated steam |
The mirrors in the CLFR array individually track the sun’s position. This tracking ensures that the solar heat is continuously focused onto the overhead pipes. The pipes contain water which boils directly into steam upon receiving the concentrated solar heat. This direct boiling process is a key feature of the solar boiler design.
Thermal Performance and Applications
The Kimberlina solar boiler currently achieves 750-degree F superheated steam. This thermal output can be utilized in two primary ways. First, the steam can spin a turbine to generate electricity. Second, the steam can be used as industrial steam for various processes. These industrial applications include food processing, oil processing, and desalination processes.
The technology is designed for efficiency and scalability. Areva Solar, the operator of the Kimberlina plant, has developed next-generation solar boilers. The next generation solar boiler under construction is designed to achieve 900-degree F superheated steam. This improvement indicates an ongoing development path for the CLFR technology. The 5 MW capacity of the Kimberlina plant demonstrates the commercial viability of this solar thermal approach. The plant was completed in 2008 and remains operational.
Technical Specifications and Steam Generation
This system consists of groups of 13 narrow, flat mirrors that individually track the sun and focus heat onto overhead pipes carrying water. The direct boiling of water into steam allows the plant to generate electricity by spinning a turbine or to provide industrial steam for food processing, oil, and desalination. The current operational solar boiler achieves a superheated steam temperature of 750-degree F.
Current and Next-Generation Steam Temperatures
| Boiler Generation | Superheated Steam Temperature |
|---|---|
| Current Operational Boiler | 750-degree F |
| Next Generation (Under Construction) | 900-degree F |
This advancement in thermal performance enhances the efficiency of the CLFR technology, allowing for greater versatility in both power generation and industrial applications. The plant's design focuses on maximizing the heat concentration on the overhead pipes to optimize steam production.
Significance
The Kimberlina Solar Thermal Energy Plant holds a distinct position in the timeline of California's renewable energy infrastructure, marking the first commercial solar thermal power plant constructed by Areva Solar. Completed in 2008, this facility represents a significant milestone as the first solar thermal plant built in the state in more than two decades, following the earlier development of the Solar Energy Generating Systems. The plant's commissioning signaled a renewed industrial interest in solar thermal technology in California, leveraging the region's established solar resources to introduce newer generation equipment into the grid. The 5 MW capacity of the Kimberlina plant serves as a demonstration of the viability of Compact Linear Fresnel Reflector (CLFR) technology for commercial electricity generation, providing a bridge between early solar thermal experiments and subsequent large-scale deployments.
Technical Certification and the ASME S-Stamp
A critical aspect of the Kimberlina plant's significance is its certification by the American Society of Mechanical Engineers (ASME). The facility is recognized as the first and only solar boiler to receive the ASME S-Stamp, a prestigious certification that validates the design, construction, and operational integrity of the steam-generating equipment. This certification is particularly important for solar thermal plants that produce superheated steam, as it allows the generated steam to be used not only for spinning turbines to generate electricity but also for direct industrial applications. The ASME S-Stamp confirms that the solar boiler meets rigorous engineering standards comparable to those applied to conventional fossil-fuel or nuclear steam generators, thereby enhancing the marketability of solar thermal steam for food processing, oil extraction, and desalination processes.
The achievement of the S-Stamp underscores the technical maturity of the CLFR technology employed at Kimberlina. By demonstrating that narrow, flat mirrors can individually track the sun and focus heat onto overhead pipes to produce reliable 750-degree F superheated steam, the plant validated the engineering assumptions behind Areva Solar's design. This certification helped establish confidence in solar thermal systems among industrial users who require consistent steam quality, distinguishing the Kimberlina plant from other solar technologies that may not have achieved the same level of mechanical engineering validation at the time of its commissioning.
Applications of Solar Thermal Steam
The Kimberlina Solar Thermal Energy Plant demonstrates the dual utility of concentrated solar power technology, producing high-grade thermal energy that serves both electrical generation and direct industrial applications. According to the, the facility uses Compact Linear Fresnel Reflector (CLFR) technology to generate superheated steam, which can then spin a turbine to generate electricity or be used as industrial steam for food, oil and desalination processes. This versatility distinguishes solar thermal energy from photovoltaic systems, which primarily produce direct current electricity. The ability to produce steam allows for direct integration into existing industrial infrastructure, providing a flexible energy solution for regions with high solar irradiance and diverse industrial needs.
Electricity Generation via Turbines
The primary function of the generated steam at Kimberlina is to drive turbines for electricity production. In a typical solar thermal setup, the superheated steam expands through a turbine, converting thermal energy into mechanical energy, which is then converted into electrical energy by a generator. The Kimberlina plant, with a capacity of 5 MW, contributes to the local grid in Bakersfield, California. The use of superheated steam, achieving 750-degree F at Kimberlina, ensures that the steam entering the turbine has sufficient enthalpy to maximize efficiency and minimize condensation within the turbine blades, thereby reducing mechanical wear and improving overall power output. This method of electricity generation allows for easier integration with conventional steam turbines, facilitating hybrid power plants or retrofits of existing thermal power stations.
Industrial Steam Applications
Beyond electricity generation, the steam produced at Kimberlina serves critical industrial processes. The notes that the steam can be used as industrial steam for food, oil and desalination processes. In the food industry, superheated steam is essential for pasteurization, sterilization, and cooking, providing a clean and consistent heat source. For the oil industry, steam is often used in enhanced oil recovery techniques, such as steam flooding, where high-temperature steam is injected into oil reservoirs to reduce the viscosity of crude oil, making it easier to extract. In desalination processes, particularly multi-effect distillation or mechanical vapor compression, the superheated steam provides the necessary thermal energy to evaporate seawater, separating fresh water from salts and impurities. The ability to produce 750-degree F superheated steam at Kimberlina makes it suitable for these high-temperature industrial demands, offering a renewable alternative to fossil-fuel-fired boilers.
Technological Advancements in Steam Temperature
The efficiency and applicability of solar thermal steam are closely tied to the temperature of the superheated steam. Higher steam temperatures generally lead to greater thermodynamic efficiency in power cycles and expand the range of industrial processes that can be effectively heated. The progression from 750-degree F to 900-degree F represents a significant technological advancement, allowing for more versatile and efficient use of solar thermal energy. This improvement enables the steam to be used in more demanding industrial applications and increases the electrical output per unit of solar energy captured, thereby enhancing the economic viability of solar thermal plants like Kimberlina.
History and Development
The Kimberlina Solar Thermal Energy Plant was completed in 2008, marking a significant milestone in the deployment of commercial solar thermal technology in California. As the first commercial solar thermal power plant built by Areva Solar, the facility established the operator’s initial foothold in the renewable energy sector. The plant is located in Bakersfield, California, and operates with a capacity of 5 MW, utilizing Compact Linear Fresnel Reflector (CLFR) technology to generate superheated steam. This completion date places the Kimberlina plant within the broader context of early 21st-century solar thermal development in the state, following earlier large-scale projects such as the Solar Energy Generating Systems (SEGS) plants in the Mojave Desert. While SEGS utilized parabolic trough technology, Kimberlina introduced the CLFR approach to the commercial grid, demonstrating the versatility of solar thermal systems. The development of Kimberlina by Areva Solar represented a strategic entry into the California market, leveraging the region’s high direct normal irradiance and growing demand for renewable energy sources. The plant’s operational status as of 2008 signifies its successful integration into the local energy infrastructure, providing a reliable source of solar-generated power. The use of CLFR technology at Kimberlina allowed for the direct boiling of water into steam, which could then be used to spin a turbine for electricity generation or serve as industrial steam for various processes. This dual-purpose capability highlighted the flexibility of solar thermal energy in meeting both electrical and thermal energy demands. The completion of the plant in 2008 also coincided with a period of increasing interest in solar energy in California, driven by state policies and incentives aimed at expanding renewable energy capacity. Areva Solar’s decision to build Kimberlina reflected a confidence in the commercial viability of CLFR technology, which offered a cost-effective alternative to other solar thermal systems. The plant’s development contributed to the diversification of California’s energy mix, adding a new technological option to the state’s solar thermal portfolio. The operational success of Kimberlina provided valuable data and experience for Areva Solar, informing the design and construction of subsequent solar thermal projects. The plant’s location in Bakersfield, a city with significant energy consumption and industrial activity, further underscored the strategic importance of the project. The completion of Kimberlina in 2008 thus represents a key moment in the history of solar thermal energy in California, showcasing the potential of innovative technologies to contribute to the state’s renewable energy goals. The plant’s continued operation serves as a testament to the enduring value of early investments in solar thermal infrastructure.
What distinguishes Kimberlina from other solar plants?
Kimberlina Solar Thermal Energy Plant distinguishes itself through its specific adoption of Compact Linear Fresnel Reflector (CLFR) technology, marking a departure from the parabolic trough systems that dominated earlier commercial solar thermal deployments. While the Solar Energy Generating Systems (SEGS) in California relied on curved parabolic mirrors to focus sunlight onto a central receiver tube, Kimberlina utilizes a group of 13 narrow, flat mirrors per solar boiler. These individual mirrors track the sun and focus heat onto overhead pipes carrying water, a configuration that simplifies the mechanical structure compared to the linear motion requirements of parabolic troughs. This technological choice was central to Areva Solar’s strategy to reduce the levelized cost of energy by leveraging flat-glass manufacturing processes and a fixed receiver height.
Technological Differentiation from Parabolic Troughs
The structural difference between CLFR and the parabolic trough technology used in the SEGS plants is significant. In a parabolic trough system, the entire mirror assembly must rotate to follow the sun, requiring complex drive mechanisms and support structures for each row. In contrast, the Kimberlina plant’s CLFR design uses flat mirrors that pivot on a single axis. This allows for a more compact layout and potentially lower land use intensity. The water in the overhead pipes boils directly into steam, which can then spin a turbine to generate electricity or be used as industrial steam for food, oil, and desalination processes. This direct steam generation capability is a key feature of the CLFR technology employed at Kimberlina.
ASME S-Stamp Certification and Industrial Steam
A critical milestone for the Kimberlina plant was its achievement of ASME S-Stamp certification. This certification is vital for solar thermal plants aiming to compete with conventional power plants in the industrial steam market. The ASME Boiler and Pressure Vessel Code S-Stamp indicates that the solar boiler meets rigorous standards for pressure vessels, allowing the generated steam to be fed directly into industrial processes without the need for a backup boiler in many configurations. Kimberlina’s solar boiler currently achieves 750-degree F superheated steam, a temperature sufficient for various industrial applications. The plant’s certification demonstrated that solar thermal energy could provide reliable, high-quality steam, expanding the market beyond pure electricity generation.
The success of the Kimberlina project paved the way for next-generation solar boilers. Areva Solar designed subsequent units to achieve 900-degree F superheated steam, further enhancing the competitiveness of CLFR technology. The plant’s operational status since 2008 provides long-term performance data for the CLFR technology, offering valuable insights for future solar thermal deployments. The 5 MW capacity of Kimberlina serves as a benchmark for the scalability and efficiency of the Compact Linear Fresnel Reflector design in commercial settings.
